1700 Laboratory Electric Muffle Furnace 8L

1700 Lab electric muffle furnace:BOX-1700 is the most cost effective bench-top high temperature muffle furnace made by SHIBO. The furnace consists of high quality alumina fiber brick and MoSi2 heating elements. The furnace temperature is controlled by high precision SCR (Silicon Controlled Rectifier) digital controller with accu

Featured Products

1700 Lab electric muffle furnace:
BOX-1700 is the most cost effective bench-top high temperature muffle furnace made by SHIBO. The furnace consists of high quality alumina fiber brick and MoSi2 heating elements. The furnace temperature is controlled by high precision SCR (Silicon Controlled Rectifier) digital controller with accuracy at +/-1 oC and 51 segments programmable up to 1700 oC or 3092 oF. It is an ideal tool for materials annealing and sintering in your research laboratory.

Mainly Specification for the BOX-1700 muffle furnace
Furnace structure:Double shell steel case with fan cooling
High purity alumina fiber insulation for max. energy saving
Chameber Size:200(W)*200(H)*200(D)mm (8*8*8inch)
Max. temperature1700C
Wok temperature:1600C
Temperature control:51 segments programable and PID auto control
Heating elements:High performance MoSi2 heater
Thermocouple:Long Life B Type Thermocouple
Heating rate:0~20°C / min (suggestion =< 10°C)
Temperature accuracy: +/-1 °C
Wok voltage:AC220V, 50/60HZ single phase or as your requirement
Max power:8KW
Net weight:150kgs
Warranty:1 year limited warranty
Certificate:CE certified
Optional items:PC data recorder, Exhauster port, Quartz observation widow, Over temperature controlle


Our standard sizes:


ModelChamber size(W× H× D mm)Max. Temperature
BOX-1700150x150x150mm (6" x6" x6" )1700. C
BOX-1700150x150x200mm (6" x6" x8" )1700. C
BOX-1700200x200x200mm (8" x8" x8" )1700. C
BOX-1700200x200x300mm (8" x8" x12" )1700. C
BOX-1700250x250x300mm (10" x10" x12" )1700. C
BOX-1700300x300x400mm (12" x12" x16" )1700. C
BOX-1700350x350x400mm (14" x14" x16" )1700. C
BOX-1700400x400x400mm (16" x16" x16" )1700. C
BOX-1700500x500x500mm (20" x20" x20" )1700. C
For other sizes, we can make as your requirement.

Application:It is an excellent product for university, science research institution, mining industry to make powder, ceramic sinter and anneal.
